Discover
V. laser
More Excellent Laser for Vascular Lesions, Pigmented Lesions & Skin Rejuvenation
Long-Pulsed 532nm KTP & 1064nm Nd:YAG Laser
V-Laser is the Long Pulse Nd: YAG laser system offers 1064nm&532nm wavelengths.
It is effective in treating various medical indications such as melasma, freckles, hyperpigmentation, or other complex skin problems (skin pore, wrinkles, elasticity).
Performance
&
Precision
FEATURES
Versatility
Long pulses of 532nm and 1064nm with various pulse duration are effective in treatments of various lesions such as vascular lesions and benign pigmented lesions in epidermis or dermis of all skin types
Flexibility
Energy, pulse duration and spot size can be flexibly adjusted to consider each lesion’s features and better results
Convenience
Three different modes(532nm, 1064nm or Genesis) are available for various treatments without changing a handpiece
​
Duration
V-Laser consists of high quality components and excellent features for long durability.
In addition there is no extra consumable part for cooling system
1.
VASCULAR LESIONS
2.
P​igmented Lesions
3.
SKIN REJUVENATION
3.
HAIR REMOVAL
INDICATION
.jpg)
Hand Pieces
.jpg)
SPECIFICATIONS
Irradiation Type Long Pulsed Nd:YAG
--------------------------------------
Wavelength 532nm, 1064nm
--------------------------------------
Pulse Duration 532nm : 1 to 40ms
1064nm: 5 to 60ms
Genesis Mode: 0.3ms
--------------------------------------
Repetition Rate 532nm: 0.5 to 3Hz
1064nm: 0.5 to 5Hz
Genesis Mode: 0.5 to 10Hz
--------------------------------------
Spot size 2, 3, 4, 5, 6, 8, 10 ,12mm
--------------------------------------
Cooling system Sapphire Glass Contact Cooling
--------------------------------------
Electrical requirements 220/230V, 50/60Hz, 4kVA
--------------------------------------
Dimension 420(W)X793.2(D)X912.5(H)mm
--------------------------------------
Weight 80kg
--------------------------------------
​
